Key Features
- Wireless Grade 3 integration module for connecting third-party wired detectors and devices to an Ajax security system with 18 wired zones
- Supports connection types including NC; NO; EOL; 2EOL; and 3EOL
- Communicates with an Ajax hub via secure two-way Superior Jeweller and Wings protocols with up to 3000m range in open space
- Powered from 100–240V~ mains and supports connection of a 12V backup battery for up to 24 hours autonomous operation
- Supplies 10.5–15V power output to connected wired detectors and devices
- Two tamper sensors detect dismantling or detachment of the integration module
- Enhanced sabotage protection including device authentication; protection against third-party device spoofing; communication loss detection; and frequency hopping against radio interference and jamming
- Can connect a variety of wired devices with over 10 selectable event types for connected devices
- KeyArm Zone setup allows third-party devices to switch arming modes
- Detects wired device issues and transmits sabotage alarms from connected devices to the Ajax system
- Remote configuration; control; firmware updates; and status monitoring via Ajax mobile and desktop apps
- EN 50131 Grade 3; PD 6662:2017; and INCERT compliant for professional high-security installations
